2026 Kia EV9 near Columbia, SC
The 2026 Kia EV9 is a three-row electric SUV engineered with a dedicated battery-electric platform, dual motor availability, high-capacity lithium-ion battery systems, and a reinforced chassis designed to support both passenger volume and towing capability. It offers rear-wheel drive and all-wheel drive configurations, multiple battery capacities, and defined acceleration metrics across trim levels. With up to 379 horsepower and 516 lb.-ft. of torque in AWD configurations, targeted driving ranges of 305 miles in select trims, and DC fast-charging capability compatible with 350 kW equipment, the 2026 Kia EV9 is structured around measurable output, efficiency, and structural precision. Every specification reflects a defined performance objective supported by detailed engineering data.
Electric Motor Configuration and Output Ratings
The 2026 Kia EV9 uses a Permanent Magnet Synchronous Motor system across all trims. Rear-wheel drive Light and Light Long Range models rely on a single rear-mounted motor, while Wind, Land, and GT-Line™ trims incorporate a dual-motor all-wheel drive layout.
The Light RWD trim produces 215 horsepower at 4,400 to 9,000 rpm and 258 lb.-ft. of torque from 0 to 4,200 rpm. The Light Long Range RWD trim produces 201 horsepower at 4,200 to 8,200 rpm and 258 lb.-ft. of torque from 0 to 4,000 rpm. AWD trims combine a 189.5 horsepower front motor with a 189.5 horsepower rear motor, generating a total system output of 379 horsepower. Total torque reaches 443 lb.-ft. with Feature-on-Demand deactivated and up to 516 lb.-ft. with Feature-on-Demand activated, depending on configuration.
Front motor torque in AWD trims measures 184.44 lb.-ft. at 0 to 2,200 rpm with FoD off and 258 lb.-ft. at 0 to 3,800 rpm with FoD on. Rear motor torque in AWD configurations measures 258.22 lb.-ft. at 0 to 3,800 rpm. This immediate torque delivery from 0 rpm supports consistent low-speed acceleration and highway merging performance.
The final gear ratio for RWD trims is 13.16 to 1. AWD trims use a 10.65 to 1 ratio in the front and 13.16 to 1 in the rear. These ratios are calibrated to balance launch response, cruising efficiency, and traction distribution.
High-Voltage Battery Engineering and Energy Density
All 2026 Kia EV9 trims use lithium-ion battery packs. The Light trim is equipped with a 76.1 kWh battery rated at 632 volts with a capacity of 120.6 Ah. The Light Long Range, Wind, Land, and GT-Line™ trims use a 99.8 kWh battery rated at 552 volts with a capacity of 180.9 Ah.
Battery power output is rated at 182 kW for the 76.1 kWh pack and 318 kW for the 99.8 kWh pack. Cell-level energy density measures 670 Wh per liter across all trims. Pack-level energy density measures 200.7 Wh per liter for the 76.1 kWh battery and 263.3 Wh per liter for the 99.8 kWh battery.
Battery volume is 379 liters for both battery sizes. The 76.1 kWh pack weighs 1,021.4 pounds, while the 99.8 kWh pack weighs 1,248.9 pounds. A 12-volt battery rated at 60 Ah supports auxiliary systems. This battery structure integrates within the floor of the vehicle to maintain a low center of gravity and structural rigidity across the 122-inch wheelbase.
Charging Architecture and Electrical Output
The 2026 Kia EV9 is equipped with a 10.9 kW onboard charger across all trims. The low-voltage DC-DC converter provides a maximum output of 2.4 kW. Maximum power density is rated at 1.4 kW per liter.
Using a dual-level ICCB at 240 volts and 30 amps, AC charging time for the 76.1 kWh battery is 11 hours and 15 minutes. For the 99.8 kWh battery, charging time is 14 hours and 35 minutes. With an 11 kW EVSE operating at 240 volts and 48 amps, charging time decreases to 6 hours and 45 minutes for the 76.1 kWh battery and 8 hours and 45 minutes for the 99.8 kWh battery.
DC fast charging with a 50 kW CCS adapter requires 63 minutes for the Light trim and 83 minutes for trims equipped with the 99.8 kWh battery. With a 350 kW EVSE limited to 310 amps, charging time decreases to 20 minutes for the Light trim and 24 minutes for the larger battery trims. Peak system power reaches 235 kW in the Light trim and 210 kW in other trims.
Disclaimer: 2 2025 EV9 GT-Line AWD pre-production model shown with optional features. Not all optional features are available on all trims. Some features may vary.
Charge time based on Kia Corporation testing on GT-Line trim with 800v 350kW DC fast charger and approximately 72 degrees Fahrenheit battery temperature. Actual charge will vary with options, driving conditions, driving habits, vehicle maintenance, charging practice, battery age, weather, temperature, and your vehicle’s condition. Battery capacity will decrease with time and use. Frequent use of DC fast charging can negatively impact battery performance and durability, and Kia recommends minimizing use of DC fast charging.
Charger sold separately.
Acceleration, Speed, and Braking Metrics
Performance varies by drivetrain configuration. The Light RWD trim accelerates from 0 to 60 mph in 7.7 seconds. The Light Long Range RWD trim completes 0 to 60 mph in 8.8 seconds. AWD trims complete 0 to 60 mph in 5.7 seconds with FoD off and 5.0 seconds with FoD on. The GT-Line™ trim achieves 5.0 seconds.
Intermediate acceleration for AWD trims measures 1.9 seconds from 19 to 44 mph with FoD on and 2.8 seconds from 37 to 62 mph. From 50 to 75 mph, acceleration measures 3.7 seconds in AWD configurations.
Maximum speed is rated at 118 mph for the Light trim, 115 mph for the Light Long Range trim, and 124 mph for AWD trims.
Braking performance from 62 to 0 mph measures 128 feet across all trims. The braking system uses ventilated disc brakes at both front and rear with rotor diameters of 14.2 inches in front and 13.6 inches in the rear. The system incorporates a Mando iEB integrated electronic brake booster and an Electric Parking Brake.
Chassis Structure and Suspension Systems
The 2026 Kia EV9 is built on a 122.0-inch wheelbase. Overall length measures 197.2 inches for most trims and 197.4 inches for the GT-Line™. Width measures 77.9 inches. Height ranges from 68.9 inches without roof rails to 70.1 inches with roof rails in the GT-Line™ trim.
Minimum ground clearance measures 7.0 inches in RWD trims and 7.8 inches in AWD trims. Approach angle measures 20.0 degrees and the departure angle measures 22.8 degrees.
The front suspension uses a MacPherson® strut with dual lower arm-type geometry. The rear suspension uses a five-link multi-link system. Shock absorbers incorporate Smart Frequency Damper Valve technology with Hydraulic Rebound Stop. Land and GT-Line™ trims include a rear self-leveling shock absorber configuration.
Steering is rack and pinion with rack-mounted motor-driven power steering. Steering ratio is 16.02 to 1 with 2.93 turns lock-to-lock. Turning circle radius measures 20.3 feet curb-to-curb.
Interior Space and Cargo Measurements
The 2026 Kia EV9 offers seven-passenger and six-passenger configurations depending on trim and seating layout. Passenger volume measures 158.8 cubic feet in the seven-passenger configuration and 160.3 cubic feet in the six-passenger Captain’s Chair configurations. The six-passenger Relaxation Chair configuration provides 157.6 cubic feet.
Front row legroom measures 41.4 inches. Second-row legroom measures 42.8 inches. Third-row legroom measures 30.8 inches with a second-row bench and up to 32.0 inches with Captain’s Chairs. Third-row legroom in the Relaxation Chair configuration measures 29.9 inches.
Front shoulder room measures 61.6 inches. Second row shoulder room measures 60.0 inches. Third row shoulder room measures 55.0 inches. Front hip room measures 59.4 inches, second-row hip room measures 57.9 inches, and third-row hip room measures 41.9 inches.
Cargo capacity behind the third row measures 20.2 cubic feet. Behind the second row, capacity measures 43.5 cubic feet. With the first row in place and rear seats folded, cargo capacity measures 81.7 cubic feet.
Frunk capacity measures 3.2 cubic feet in RWD trims and 1.8 cubic feet in AWD trims. Frunk payload measures 88 pounds in RWD trims and 44 pounds in AWD trims.
Towing Capacity and Weight Ratings
Curb weight for RWD trims ranges from 5,106 pounds to 5,370 pounds depending on configuration. AWD trims range from 5,714 pounds to 5,851 pounds. The Gross Vehicle Weight Rating measures 6,415 pounds for the Light RWD trim and up to 7,187 pounds for AWD trims.
Towing capacity without brakes measures 1,000 pounds in RWD trims and 1,653 pounds in AWD trims. With brakes, towing capacity measures 2,000 pounds in RWD trims. Land, GT-Line™, and GT trims support up to 5,000 pounds when properly equipped. Other AWD trims support up to 3,500 pounds with brakes.
Energy Efficiency and Driving Range Data
Targeted all-electric driving range measures 230 miles for the Light RWD trim and 305 miles for the Light Long Range RWD trim. AWD Wind and Land trims are rated at 283 miles. The AWD GT-Line™ trim is rated at 280 miles.
Fuel economy ratings for RWD trims measure up to 101 MPGe city, 76 to 78 MPGe highway, and 88 to 89 MPGe combined depending on configuration. AWD trims measure up to 94 MPGe city, 75 MPGe highway, and 84 MPGe combined, with the GT-Line™ rated at 92 MPGe city, 72 MPGe highway, and 82 MPGe combined.
Disclaimer: Based on EPA estimates on a full battery charge. Actual range will vary with options, driving conditions, driving habits, vehicle maintenance, charging practice, battery age, weather, temperature, and your vehicle’s condition. Battery capacity will decrease with time and use. For more information on range, please see www.fueleconomy.gov.
